MP 4-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 4 x 40 Watts Rms @ 4-Ohm

MP 4-Channel Full-Range Class D IP67 Marine and Powersports Amplifier 4 x 40 Watts Rms @ 4-Ohm

Regular price $149.95 USD
Regular price Sale price $149.95 USD
Sale Sold out

PRODUCT OVERVIEW

DS18 MP.4A


In the rugged world of motorsports, where water, dust, and vibrations relentlessly test your audio gear, the MP.4A stands strong. Encased in a striking brushed red aluminum body, it's not only stylish but also exceptionally durable. The MP.4A is designed to brave the elements with its IPX5 waterproofing, ensuring your music never falters, whether you're embarking on a dusty off-road adventure or a serene seaside drive. And for added protection, we've fortified the MP.4A with Salt & Fog Protection.

Connecting your audio source is a breeze, thanks to the 3.5mm jack input audio connector and RCA left and right audio outputs. These features allow you to seamlessly link other amps to it or integrate it into your current system. Every note and beat are faithfully reproduced, thanks to a raw MAX Power of 480W, delivering an exhilarating sensory experience that will send shivers down your spine. The continuous power output of 4 x 40W RMS ensures unmatched clarity and precision in your sound, with a frequency response spanning from 20Hz to 20KHz and a signal-to-noise ratio of 82dB, making every note crisp and every beat pronounced.

Installation is a breeze, thanks to the MP.4A's power direct harness design, eliminating unnecessary complexity while maximizing performance. What sets the MP.4A apart is not just its performance but also its compact size. It's so small that it can fit almost anywhere in your setup. It also incorporates surface mount component technology, ensuring reliability and longevity even in the harshest conditions. No need for complicated adjustments; it arrives ready to pump out your favorite tunes with crystal-clear precision, allowing you to fully immerse yourself in the music.





SPECS

SKU
MP.4A
Total Watts (Peak)
480W
RMS Power
4 x 40W
Frequency Response
20Hz-20KHz
Signal to Noise Ratio
82dB
Efficiency @ 4ohm
80%
Damping Factor
200
Total Harmonic Distortion (THD)
0.1%
Low Level Input Range
2.5V (Fixed)


FEATURES

Amplifier Class
Digital (D)
Amplifier Type
Stereo Full Range
Number of Channels
4
Minimum Impedance
4 Ohm Stereo (Not Bridgeable)
Power Input Terminal Size
16GA
Fuse Size
20A
Voltage Operation
9-15V DC
Thermal Protection
Yes (>75°C)


FEATURES

Body Color / Finish
Brushed Red Aluminum
Input Audio Connector
3.5mm jack
Audio Output
Yes, RCA left and right
Waterproof Rating
IPX5
Salt Fog Protection
Yes
Power Direct Harness Design
Yes
Surface Mount Component Technology
Yes
Marine Grade Fuse Holder
Yes


MEASUREMENT

Overall Length
6" / 153mm
Overall Width
3.66" / 93mm
Overall Height
1.96" / 50mm
Heatsink Length
4.72" / 120mm
Gross Single Unit Weight
1.62Lb / 735g
