DS18 PRO-TWN6.8 4" PRO High Compression Neodymium Tweeter 1.25" Voice Coil 8 Ohm

Name: DS18 PRO-TWN6.8 4" PRO High Compression Neodymium Tweeter 1.25" Voice Coil 8 Ohm
Brand: SoLow Audio
Price: 59.95 USD
Availability: InStock

$59.95 USD

Oferta Agotado

Variantes de producto

Cantidad

SPECIFICATIONS
Nominal Diameter	4" / 100mm
Nominal Impedance	8 ohms
AES Power Handling	75 Watts
Program Power Handling	150 Watts
Peak Power Handling	300 Watts
Sensitivity (1w/1m)	109 dB
Frequency Response	2K-20KHz
Recommended Hi Pass Crossover	3KHz
BODY/ FEATURES
Pair or Single	Single
Body Material	Alumium
Body Color / Finish	Black / Machined
Bullet Material	Alumium
MOTOR
Voice Coil Diameter	1.25" / 32mm
Voice Coil Former Material	Kapton
Winding Material	CCAR
Diaphragm Material	Polyimide
Magnet Material	Neodymium
Magnet Weight	1.05 oz
MEASUREMENT
Overall Diameter	3.93" / 100mm
Overall Depth	1.96" / 50mm
Front Mount Baffle Cutout	3.22" / 82mm
Mounting Depth	1.77" / 45mm

DS18 PRO-TWN6.8 4" PRO High Compression Neodymium Tweeter 1.25" Voice Coil 8 Ohm

The PRO-TWN Series Tweeter, a staple in the competitive professional audio scene, is back with boosted brilliance and clarity.

This 4” Neodymium Super Bullet Tweeter is equipped with a 1.25” Voice Coil and handles AES power at 75W, Program Power at 150W, and Peak Power at 300W. The neodymium magnet increases the tweeters efficiency and significantly lowers its weight.

With an extremely high sensitivity of 109 dB, it doesn’t take too much for these tweeters to get extremely LOUD! With minimal amounts of power, these tweeters still deliver vibrant highs with endless altitude!

This 8-ohm tweeter is guaranteed to enrich your high frequency response and would be a complement to every sound system!

Highlights

Pro Audio Super Tweeter that produces crazy loud high range notes for your system.
8 ohm impedance allows for efficient power consumption
Designed to fit in most spaces with slight modification or fabrication.

Great For
